Printing Method: Direct Thermal Printing & Thermal Transfer Printing

Two Rolls loading for labels or wristbands with switch button to select printing channel

Functions & Advantages

Direct thermal printing with maximum width of 108mm. 300dpi resolution enables it to print all sorts of one-dimensional barcodes, 2D barcodes and various graphics with high precision.

Two Rolls loading for labels or wristbands with easy switch button for any selection. Patented design of printing path with open buttons makes it easier to fix paper jam.

Printer screen displays in many languages while printer software supports printing

different languages also. Baobi Printer Driver supports creating various specifications of

consumables, which helps to quickly create new printing templates. Supporting docking

with client’s system via BPL interface file, to achieve real-time printing of data.

Baobiwanxiang patent designed thermal transfer ribbon box, makes it easy for assembling and removing ribbons.

Adopting LCD Display to show real-time printing status and quantities.

It will improve work efficiency with using Baobi Barcode Verifier to read barcode.

Application

（1）Medical

Patient Identification / Infant Anti-theft System / Sample Tracking / Drug Management / Medical Instrument Management

（2）Public Server Management

Event Ticket / Water Park / Amusement Park / Concert / Cruise / Hotel Ticket / Wristband Printing

（3）Retail

Store Merchandise Tag / Linear Label Printing

（4）Manufacturing / Logistics

Cargo Tracking / Container Label / Product Label Printing / Warehousing Identification

（5）Enterprise Office

Assets Management / File Consolidation / Company Logo Identification

FEATURES

Printing method: Direct Thermal Printing & Thermal Transfer Printing

Baobiwanxiang patent designed thermal transfer ribbon box, makes it easy for assembling and removing ribbons

Two Rolls design, easy to switch printing material

More easier and faster to set

Equipped with multiple languages

Adopting LCD Display to show real-time printing status and quantities.

Label printing software supports the printing of different language texts

Standard tear paper mode

Unique energy control of printer head

PRINTER SPECIFICATIONS

Resolution

300 dpi/12 dots per mm

Print Width

Maximum: 4.25” /108mm

Minimum: 0.39” / 10mm

Print Speed

Selectable

Standard Speed: 2.5” /60mm per second

Maximum Speed: 5 ips/120mm per second

Printing mode

Direct thermal Printing, Thermal Transfer Printing

Two Rolls

Upper Roll/ Down Roll, selectable

Applicable thermal printing ribbons specification

Shaft core: 0.5 inch

Length of shaft: 108mm

Width of thermal transfer ribbon: < 108mm

Outer diameter of thermal transfer ribbon roll: < 36mm

OPERATING CHARACTERISTICS

Environmental

Operating temperature: 40℉/4.4℃ to 104℉/40℃

Storage temperature: -40℉/-40℃to 140 ℉/80℃

Operating humidity: 20%-85% non-condensing

Storage humidity: 5%-85% non-condensing

Electrical

Universal power supply (PFC compliant) 100-240VAC, 50-60Hz (60 Watts) External Power Supply

Physical Characteristics

Width: 225mm

Height: 306mm

Depth: 345mm

Weight (N.W): 3.66kg

BAOBI PRINTABLE ID SOLUTION

Software

BAOBI Printer Driver

BBDesigner

Programming

BPL+ (Application Programming Interface)

Networking /Connectivity

USB 2.0 interface

Ethernet 10/100 interface

Wireless 802.11 b/g/n (Optional)

Font and Graphic

Support user-defined fonts and graphics-including custom logo

Font and Barcode rotation: 90, 180, 270 degrees

Barcode

Linear Barcode: Code 39, Code 128A, B&C, UCC/EAN-128, Code 93, Codabar, Interleaved 2 of 5, UPC-A, UPC-E, UPC-A with 2 and 5 add on, UPC-E with 2 and 5 add on, EAN 13, EAN 8, EAN 13 with 2 and 5 add on, EAN 8 with 2 and 5 add on, Postnet, Standard 2 of 5, Industrial 2 of 5, LOGMARS, MSI, Codabar and GS1 Databar (formerly RSS), Code 11, China Post.

2-Dimensional Barcode: PDF-417, Maxicode, Data Matrix, QR code, Aztec.

Accessories

Software CD Disk (BBDesigner / BAOBI Printer Driver)

Warranty Card

USB Port Cable

Power Adapter

Power Cord

BAOBI Label Holder WH01 (Optional)

BAOBI Ribbon Shaft BRS01 (Optional)
